RD55D-CD
Dimension Size : 55″
Bezel : 3.5mm
Brightness(cd/m²) : 700cd/m²
Contrast Ratio : 1400:1
Redevue RD55D-CD is a high brightness narrow bezel LCD Video Wall Display with screen diagonals of 55″ with combined bezel-to-bezel at 3.5mm. It comes with DisplayPort for Daisy-Chain to form a video wall without external controller. The display comes with Full HD Resolution in LED Backlight technology. The brightness of the display reaches up to 700 nits and 1400:1 of contrast ratio. The display comes with numerous of features to guarantee the reliability for 24/7 Control Room environment usage.
Specifications
Panel Size                         55″
Outer Size                         1213.5 x 684.3 x 123 mm
Packing Size                        1448 x 253 x 935 mm
Gross weight                       27 kg
Viewing Area (L x H)Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â 1209.6 x 680.4 mm
Contrast Ratio                      1400:1
Resolution                         1920 x 1080
Brightness                         700cd/m²
Combined Bezel For Two Panels     ≤ 3.5mm
Backlight                           LED
Viewing Angle                      178° / 178° (H, V)
Power                             250W
Response Time                     8ms
Using Life                          50,000(hrs)
Control Interface                   RS232
Spliced Quantity                   Any M line x Any N Row
Temperature / Humidity            0℃ ~ 50℃ / 10% ~ 90% (no condensation)
Installation                        Floor standing, wall mount, cabinet
Input Signal                        2 x HDMI in, 1 x DVI in, 1 x VGA in, 1 x DP in, 1 x Audio out, 1 x Audio In, 1 x DP out, 1 x RS232 in, 1 x RS232 out,                                                1 x AC100-240V
Accessories                         User Manual, Power cable, RJ45 Cable, IR receiver, Remote controller, HDMI/ DVI cable, USB-RS232 converter, RS232 to                                         RJ45 converter .
