RD55D-C
Dimension Size : 55″
Bezel : 3.5mm
Brightness(cd/m2) : 700 cd/m²
Contrast Ratio : 1400:1
Redevue RD55D-C is a high brightness narrow bezel LCD Video Wall Display with screen diagonals of 55″ with combined bezel-to-bezel at 3.5mm. The display comes with Full HD Resolution in LED Backlight technology. The brightness of the display reaches up to 700 nits and 1400:1 of contrast ratio. The display comes with numerous of features to guarantee the reliability for 24/7 Control Room environment usage.
Specifications
Panel Size                         55″
Outer Size                         1213.5 x 684.3 x 123mm
Viewing Area (L x H)Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â 1209.6 x 680.4mm
Gross Weight                      75kgs
Contrast Ratio                      1400:1
Resolution                         1920 x 1080
Brightness                         700cd/m2
Combined Bezel For Two Panels     ≤3.5 mm
Backlight                           LED
Viewing Angle                      178° / 178° (H, V)
Power                              250W
Response Time                     8ms
Using Life                           50,000(hrs)
Control Interface                   RS232
Spliced Quantity                    Any M line x Any N Row
Temperature / Humidity             0℃ ~ 60℃ / 10% ~ 90% (No Condensation)
Input Signal                        1 x USB, 1 x HDMI in, 2 x DVI in, 1 x VGA in, 1 x AV in, 1 x AV out, 1 x Audio out, 1 x RS232 in, 1x RS232 out.
